Three-Finger-Drag (Linux, …)

draggg Banner

Features

  • macOS-style three-finger drag: Natural dragging gestures with three fingers
  • Intelligent finger tracking: Weighted position tracking with leading finger emphasis
  • Multi-touchpad support: Works with Apple trackpads and standard Linux touchpads
  • Automatic hardware detection: Automatically finds and configures your touchpad
  • Customizable sensitivity: Adjust drag sensitivity and movement thresholds
  • Left-handed support: Configurable for left-handed users
  • Background service: Optional systemd service for always-on operation
  • X11 compatible: Works with X11 display server (recommended)

How It Works: Finger Tracking and Offset Methods

Index Finger Tracking Algorithm

draggg uses an intelligent weighted position tracking system that emphasizes the leading finger (typically the index finger) while incorporating input from all three fingers:

1. Leading Finger Identification

The system identifies the “leading finger” based on hand orientation: - Right-handed users: Leftmost finger (lowest X coordinate) - typically the index finger - Left-handed users: Rightmost finger (highest X coordinate) - typically the index finger

This is determined by sorting all three finger positions by X coordinate and selecting the appropriate edge based on the left_handed configuration.

2. Weighted Position Calculation

The tracking position is calculated using a weighted average:

weighted_x = (leading_x × leading_weight + finger2_x × other_weight + finger3_x × other_weight) / total_weight
weighted_y = (leading_y × leading_weight + finger2_y × other_weight + finger3_y × other_weight) / total_weight

Default weights: - Leading finger (index finger): 1.5 (50% more influence) - Other two fingers: 0.3 each (30% combined influence)

This weighting scheme provides: - Smooth tracking: The leading finger dominates, reducing jitter from fingers moving at slightly different rates - Natural feel: Mimics single-finger cursor movement while maintaining three-finger gesture recognition - Stability: Other fingers provide stabilizing input without overwhelming the primary tracking finger

3. Offset Calculation Method

Once dragging begins, the system uses an offset-based approach to translate finger movement to cursor movement:

Step 1: Initial Position Lock - When three fingers are detected, the system records: - Current cursor position (cursor_lock_position) - Initial weighted finger position (initial_left_finger_position)

Step 2: Movement Offset Calculation For each frame during dragging:

offset_x = current_finger_x - initial_finger_x
offset_y = current_finger_y - initial_finger_y

Step 3: Cursor Position Update The offset is applied to the locked cursor position with sensitivity scaling:

new_cursor_x = cursor_lock_position_x + (offset_x × drag_sensitivity)
new_cursor_y = cursor_lock_position_y + (offset_y × drag_sensitivity)

Step 4: Relative Movement Emission The system calculates relative movement from the last position and emits it via uinput:

dx = new_cursor_x - last_cursor_x
dy = new_cursor_y - last_cursor_y

This dual-mode approach ensures: - Absolute positioning: When cursor position is available (via xdotool/X11), provides precise control - Relative fallback: When cursor position is unavailable, uses pure relative movement for compatibility

4. State Machine Flow

The gesture recognition follows this state progression:

  1. IDLE: No gesture active
  2. THREE_FINGER_DETECTED: Three fingers detected, starting 50ms detection delay
  3. LOCKING_POSITIONS: Delay elapsed, locking cursor and finger positions
  4. WAITING_FOR_THRESHOLD: Waiting for movement to exceed threshold (default: 10 pixels)
  5. DRAGGING: Actively dragging, tracking finger movement and updating cursor
  6. RELEASING: Fingers lifted, waiting 30ms before releasing mouse button
  7. IDLE: Back to idle state

5. Micro-Delays for Stability

The system includes small delays to prevent accidental activations: - Detection delay (50ms): Prevents activation from brief three-finger touches - Click delay (20ms): Small delay before mouse button press for stability - Release delay (30ms): Prevents premature release during finger adjustments

Why This Approach Works

  1. Leading Finger Emphasis: By giving the index finger (leading finger) more weight, the system tracks the finger that users naturally use to guide movement, resulting in intuitive control.

  2. Offset-Based Movement: Using offsets from an initial position rather than absolute positions prevents cursor jumps and provides smooth, predictable movement.

  3. Sensitivity Scaling: The drag_sensitivity parameter (default 0.25) allows fine-tuning of movement responsiveness, making it adaptable to different touchpad sizes and user preferences.

  4. Weighted Averaging: Incorporating all three fingers while emphasizing the leading finger provides stability without sacrificing responsiveness.
